DC-3

No.DC-3
Quick Details Place of Origin: Hebei, China (Mainland) Brand Name: Z&l Warranty: 1 Years
  • DC-3
  • DC-3
  • DC-3
  • DC-3
  • DC-3
Desciption
Introduction
Standard breathers provide simple, yet dependable protection from moisture and particulate
contamination in lubricants and equipment across multiple industries and applications.
These versatile breathers are five times more effective than the leading non-desiccant
breathers, providing optimal defense against humidity for your applications.


Specification
P/N       Filter mic. Working Tepm. Dosage of Desiccants Water Absorption Filter Area Connection size
DC-BB 3μm -29℃~93℃ ≥0.127kg 0.0497L 24 cm² 3/8(NPT,BSPP,BSPT)
DC-1 3μm -29℃~93℃ ≥0.127kg 0.0497L 24 cm² 3/8(NPT,BSPP,BSPT)
DC-2 3μm -29℃~93℃ ≥0.3kg 0.1182L  74cm² 1"(NPT,BSPT)
DC-3 3μm -29℃~93℃ ≥0.56kg 0.2203L  74cm² 1"(NPT,BSPT)
DC-4 3μm -29℃~93℃ ≥0.84kg 0.333L  74cm² 1"(NPT,BSPT)
HG-1 3μm -40℃~90℃ 0.225kg 0.086kg 752cm² G3/4 BSP
HC-8 3μm -40℃~90℃ 0.5kg 0.145kg 800cm² G3/4 BSP
ND-1 3μm -40℃~90℃ 0.45kg 0.172kg 752cm² G3/4 BSP
VG-BB 3μm -40℃~90℃ 0.75kg 0.288kg 2095cm² G1-1/4 BSP
VB-1 3μm -40℃~90℃ 1.5kg 0.576kg 2095cm² G1-1/4 BSP
VG-2 3μm -40℃~90℃ 0.45kg 0.038kg 752cm² G3/4 BSP
VG-3 3μm -40℃~90℃ 0.75kg 0.288kg 2095cm² G1-1/4 BSP
VG-4 3μm -40℃~90℃ 1.5kg 0.576kg 2095cm² G1-1/4 BSP
Application
Application Totes/transformer/storage tanks/hydraulics
Operation The desiccant breather replaces the standard dust cap or OEM breather cap on equipment. As air is drawn into equipment through the breather, the layered filter elements remove particulate while the desiccant beads strip harmful moisture. While in service or during shut-down, the desiccant beads attract moisture from inside the equipment reservoir, actively drying the equipment.
Principle Removes moisture in the headspace of equipment
Eliminates rust-forming condensation
Prevents sludge deposits and water-contaminated oil
Prevents contamination ingress
Provides longer lubricant life
Reduces wear and tear on equipment, prolongs life
Alternative adapter Form
Related Series Adapter types
DC-10-S 1" FNPT x 1" Slip Fit Adapter
DC-10 1" Threaded Adapter
DC-10-T 1" Male Threaded x 1" Female Threaded Adapter
DC-17 Bell Reducer 1" to 3/4"-Slip Fit
DC-17-T 1"-3/4" Female to Male Threaded Adapter
DC-18 1"-1/4" Brass, Threaded Reducer/Adapter
DC-12-T Threaded Flange Adapter
DC-12-TG Threaded Flange Adapter with Gasket
DC-15-T Bayonet Adapter
DC-SDVA-12M 3/4" NPT Vent Valve Adapter for Standard and VentGuard Breathers
DC-SDVA-16M 1" NPT Vent Valve Adapter for Standard and VentGuard Breathers
